Name: OE NO.90919-02239 Ignition Coil Boot For Toyota Corolla
Brand: Axis (xi'an)Technology Co.,Ltd.

OE NO.90919-02239 Ignition Coil Boot For Toyota Corolla

Perfect Fit For:

Toyota Corolla (2000-2008) 1.8L I4
Pontiac Vibe (2003-2008) 1.8L I4 (Non-GT)
Toyota Matrix (2003-2008) 1.8L I4
Chevrolet Prizm (2000-2002) 1.8L I4
Toyota Celica GT (2000-2005) 1.8L I4 (Not GTS)

Contact with Us

Tel:

E-mail:

Add:

Room 502, Block D, Galaxy Huating, No. 149 Weiyang Road, Xi'an, Shaanxi Province, China

Axis

For inquiries about our rubber sealing products, please fill out the form below, and we will respond promptly.

Popular Ignition Coil Boot

03 Aug

03 Aug

03 Aug

Product Name		OEM Ignition Coil Boot For 2000-2008 Toyota Pontiac Chevrolet 1.8L, 90919-02239
OE Number		9091902239 9008019015 9008019015 9008019019 9091902262 90919T2002 UF247
Compatibility		2000, 2001, 2002 Chevrolet Prizm 1.8L I4 2003, 2004, 2005, 2006, 2007, 2008 Pontiac Vibe (Not fit GT) 1.8L I4 2000, 2001, 2002, 2003, 2004, 2005 Toyota Celica GT (Not fit GTS) 1.8L I4 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008 Toyota Corolla 1.8L I4 2003, 2004, 2005, 2006, 2007, 2008 Toyota Matrix 1.8L I4 2000, 2001, 2002, 2003, 2004, 2005 Toyota MR2 Spyder 1.8L I4
Material		Silicone Rubber
Temperature Rang		Continuous: -40°C ~ +200°C
Voltage Resistance		Dry: ≥30 kV Wet: ≥15 kV（95% RH）
Hardness (Shore A)		55 Shore A
Dimensions		（ID）: 8.5mm ±0.2 （OD）: 18.0mm ±0.3 （Length）: 60mm ±1

High-Temperature Stability		Temperature Range: -40°C ~ +200°C (peak 230°C), ideal for turbocharged engines. Thermal Aging: ≤10% hardness change & ≥85% elasticity retention after 500h at 200°C.
High-Voltage Insulation		Withstands 30 kV (dry) & 15 kV (wet), prevents arcing. Anti-arcing inner texture reduces charge accumulation, compatible with EA888 Gen3 ignition.
Chemical Resistance		Resists ethanol-blended fuels (E10/E20) with ≤8% volume swelling. Resistant to coolant vapors (ethylene glycol-based)

OE NO.90919-02239 Ignition Coil Boot For Toyota Corolla
