Name: OE NO.077-905-115E Ignition Coil Boot For Audi S4
Brand: Axis (xi'an)Technology Co.,Ltd.

OE NO.077-905-115E Ignition Coil Boot For Audi S4

Contact with Us

Tel:

E-mail:

Add:

Room 502, Block D, Galaxy Huating, No. 149 Weiyang Road, Xi'an, Shaanxi Province, China

Axis

For inquiries about our rubber sealing products, please fill out the form below, and we will respond promptly.

Popular Ignition Coil Boot

03 Aug

03 Aug

03 Aug

Product Name		Ignition Coil Boot For Audi S4 2004-2006 2007-2009 4.2L V8 077905115E
OE Number		077905115Q 077905115A 077905115B 077905115C 077905115E 077905115F UF418
Compatibility		2005-2006 Audi A6 Quattro 4.2L V8 2003-2006 Audi A8 Quattro 4.2L V8 2003-2005 Audi Allroad Quattro 4.2L V8 2005-2009 Audi S4 4.2L V8 2004 Volkswagen Touareg 4.2L V8
Material		Silicone Rubber
Temperature Rang		Continuous: -40°C ~ +200°C
Voltage Resistance		Dry: ≥30 kV Wet: ≥15 kV（95% RH）
Hardness (Shore A)		55 Shore A
Dimensions		（ID）: 11.5mm ±0.2 （OD）: 22.0mm ±0.4 （Length）: 75mm ±1.5

High-Temperature Stability		Temperature Range: -40°C ~ +200°C (peak 230°C), ideal for turbocharged engines. Thermal Aging: ≤10% hardness change & ≥85% elasticity retention after 500h at 200°C.
High-Voltage Insulation		Withstands 30 kV (dry) & 15 kV (wet), prevents arcing. Anti-arcing inner texture reduces charge accumulation, compatible with EA888 Gen3 ignition.
Chemical Resistance		Resists ethanol-blended fuels (E10/E20) with ≤8% volume swelling. Resistant to coolant vapors (ethylene glycol-based)

OE NO.077-905-115E Ignition Coil Boot For Audi S4
