Name: OE NO.27301-3C000 Ignition Coil Boot For Changan Yuexiang、Kia Carens
Brand: Axis (xi'an)Technology Co.,Ltd.

OE NO.27301-3C000 Ignition Coil Boot For Changan Yuexiang、Kia Carens

Contact with Us

Tel:

E-mail:

Add:

Room 502, Block D, Galaxy Huating, No. 149 Weiyang Road, Xi'an, Shaanxi Province, China

Axis

For inquiries about our rubber sealing products, please fill out the form below, and we will respond promptly.

Popular Ignition Coil Boot

Product Name		OEM Ignition Coils Boot For 2010-2019 Hyundai & Kia V6, 27301-3C000
OE Number		273013C000 UF546
Compatibility		2012, 2013, 2014, 2015, 2016, 2017 Hyundai Azera 3.3L V6 2014, 2015 Kia Cadenza 3.3L V6 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018 Hyundai Santa Fe 3.3L V6 3.5L V6 2013, 2014, 2015, 2016, 2017, 2018, 2019 Hyundai Santa Fe XL 3.3L V6 2011, 2012, 2013, 2014, 2015, 2016, 2017 Kia Sedona 3.3L V6 3.5L V6 2011, 2012, 2013, 2014, 2015, 2016, 2017 Kia Sorento 3.3L V6 3.5L V6 2012, 2013, 2014, 2015, 2016 Hyundai Genesis 3.8L V6 2010, 2011, 2012, 2013, 2014, 2015, 2016 Hyundai Genesis Coupe 3.8L V6 2015, 2016, 2017 Kia K900 3.8L V6
Material		Silicone Rubber
Temperature Rang		Continuous: -40°C ~ +200°C
Voltage Resistance		Dry: ≥30 kV Wet: ≥15 kV（95% RH）
Hardness (Shore A)		55 Shore A

High-Temperature Stability		Temperature Range: -40°C ~ +200°C (peak 230°C), ideal for turbocharged engines. Thermal Aging: ≤10% hardness change & ≥85% elasticity retention after 500h at 200°C.
High-Voltage Insulation		Withstands 30 kV (dry) & 15 kV (wet), prevents arcing. Anti-arcing inner texture reduces charge accumulation, compatible with EA888 Gen3 ignition.
Chemical Resistance		Resists ethanol-blended fuels (E10/E20) with ≤8% volume swelling. Resistant to coolant vapors (ethylene glycol-based)

OE NO.27301-3C000 Ignition Coil Boot For Changan Yuexiang、Kia Carens
